04 Burner
ecoTEC plus 612 VU 126/3-5 + R1, ecoTEC plus 615 VU 156/3-5 + R1
ecoTEC plus 618 VU 186/3-5 + R1, ecoTEC plus 624 VU 246/3-5 + R1
ecoTEC plus 630 VU 306/3-5 + R1, ecoTEC plus 637 VU 376/3-5 R1
Pos. Art.-No Part Type, note
02-04-038
00 0020010641 conversion set H -> P (not shown)
00 0020010642 conversion set P -> H (not shown)
01 049324 burner VU 126/3-5, with parts 02, 03
01 049324 burner VU 126/3-5 R1, with parts 02, 03
01 049324 burner VU 156/3-5, with parts 02, 03
01 049324 burner VU 156/3-5 R1, with parts 02, 03
01 049324 burner VU 186/3-5, with parts 02, 03
01 049324 burner VU 186/3-5 R1, with parts 02, 03
01 049345 burner VU 246/3-5, with parts 02, 03
01 049345 burner VU 246/3-5 R1, with parts 02, 03
01 050430 burner VU 306/3-5, with parts 02, 03
01 050430 burner VU 306/3-5 R1, with parts 02, 03
01 050430 burner VU 376/3-5 R1, with parts 02, 03
02 981103 sealing ring, cpl.
03 105900 screw, cpl. (set of 10)
04 114828 flanged nut
05 161245 inspection glass
06 090709 ignition/monitoring electrode
07 980961 gasket electrode
08 118883 screw
09 193590 ignition cable
10 193593 fan with parts 11, 12
11 981104 packing ring cpl.
12 193594 packingring cpl.
13 053488 gas valve VU 126/3-5, with parts 11, 14, 21
13 053488 gas valve VU 126/3-5 R1, with parts 11, 14, 21
13 053488 gas valve VU 156/3-5, with parts 11, 14, 21
13 053488 gas valve VU 156/3-5 R1, with parts 11, 14, 21
13 053470 gas valve VU 186/3-5, with parts 11, 14, 21
13 053470 gas valve VU 186/3-5 R1, with parts 11, 14, 21
13 053471 gas valve VU 246/3-5, with parts 11, 14, 21
13 053471 gas valve VU 246/3-5 R1, with parts 11, 14, 21
13 053500 gas valve VU 306/3-5, with parts 11, 14, 21
13 053500 gas valve VU 306/3-5 R1, with parts 11, 14, 21
13 053500 gas valve VU 376/3-5 R1, with parts 11, 14, 21
14 981142 packingring (set of 10)
16 193586 harness VU 126/3-5
16 193586 harness VU 126/3-5 R1
16 193586 harness VU 156/3-5
16 193586 harness VU 156/3-5 R1
16 193586 harness VU 186/3-5
16 193586 harness VU 186/3-5 R1
16 193586 harness VU 246/3-5
16 193586 harness VU 246/3-5 R1
16 0020025036 harness VU 306/3-5
16 0020025036 harness VU 306/3-5 R1
16 0020025036 harness VU 376/3-5 R1
17 193595 insulation with parts 02, 03
18 - - not available as spare part, see pos. 30
19 981107 packing ring cpl.
Subject to alteration !
Attention: Please take the gross price from the valid price list !
23

Vaillant ecoTEC plus 618 Specifications

General

Model	ecoTEC plus 618
Category	Boiler
Output	18 kW
Dimensions	720 x 440 x 338 mm
Fuel Type	Natural Gas
ERP Rating	A
Mounting	Wall-mounted
Warranty	5 years
Boiler Type	Combi
Efficiency	94%
