04 Burner
ecoTEC plus 612 VU 126/3-5 + R1, ecoTEC plus 615 VU 156/3-5 + R1
ecoTEC plus 618 VU 186/3-5 + R1, ecoTEC plus 624 VU 246/3-5 + R1
ecoTEC plus 630 VU 306/3-5 + R1, ecoTEC plus 637 VU 376/3-5 R1
Pos. Art.-No Part Type, note
02-04-038
20 193597 screw, cpl. (set of 10)
21 0020025929 sealing gasket
22 193599 air inlet duct, cpl. VU 126/3-5, with part 23
22 193599 air inlet duct, cpl. VU 126/3-5 R1, with part 23
22 193599 air inlet duct, cpl. VU 156/3-5, with part 23
22 193599 air inlet duct, cpl. VU 156/3-5 R1, with part 23
22 193599 air inlet duct, cpl. VU 186/3-5, with part 23
22 193599 air inlet duct, cpl. VU 186/3-5 R1, with part 23
22 103404 air inlet duct, cpl. VU 246/3-5, with part 23
22 103404 air inlet duct, cpl. VU 246/3-5 R1, with part 23
22 103404 air inlet duct, cpl. VU 306/3-5, with part 23
22 103404 air inlet duct, cpl. VU 306/3-5 R1, with part 23
22 0020025039 air inlet duct, cpl. VU 376/3-5 R1, with part 23
23 981111 packingring cpl.
24 103405 support, cpl.
25 235756 screw
26 - - not available as spare part, see pos. 30
27 180945 gas pipe with part 28
28 0020010868 adaptor piece (gas valve)
29 982319 O-ring seal
30 0020010867 flange (set) with parts 02, 03, 04, 05, 07, 08, 12, 14, 17, 19, 20, 21
Subject to alteration !
Attention: Please take the gross price from the valid price list !
25
