07 Casing parts
ecoTEC plus 824 VUW 246/3-5 + R1
ecoTEC plus 831 VUW 316/3-5 + R1
ecoTEC plus 837 VUW 376/3-5 R1
Pos. Art.-No Part Type, note
02-07-073
01 180932 flue adapter 60/100 with parts 02, 03, 04
02 147392 cap (set of 5)
03 981232 packingring
04 981233 packingring
05 180935 covering, cpl. VUW 246/3-5, with parts 06, 07, 08, 09, 10, 11
05 180935 covering, cpl. VUW 246/3-5 R1, with parts 06, 07, 08, 09, 10, 11
05 180935 covering, cpl. VUW 316/3-5, with parts 06, 07, 08, 09, 10, 11
05 180935 covering, cpl. VUW 316/3-5 R1, with parts 06, 07, 08, 09, 10, 11
05 180937 covering, cpl. VUW 376/3-5 R1, with parts 06, 07, 08, 09, 10, 11
06 118096 badge, cpl.
07 180940 cover with parts 09, 10, 11
08 180944 hinge with part 11
09 180941 magnet, cpl. (set of 2)
10 180942 handle
11 193538 screw (set of 10)
12 180988 cover cpl.
13 180987 support, cpl.
14 139231 screw
15 500046 screw
16 - - not necessary
17 - - not necessary
Subject to alteration !
Attention: Please take the gross price from the valid price list !
9

Vaillant ecoTEC plus 824 Specifications

General

Model	ecoTEC plus 824
Category	Boiler
Type	Combination Boiler
Output	24 kW
Dimensions (H x W x D)	720 x 440 x 338 mm
Efficiency	89.3%
Energy Efficiency Class	A
Mounting	Wall-mounted
ERP Rating	A
DHW Output (kW)	24 kW
Maximum Working Pressure	3 bar
Weight	34 kg
Fuel	Natural Gas
Warranty	5 years
