Installation instructions Mixer module VR 60 0020020171_022
Contents
1 Notes on the documentation .........................2
2 Description of the device ...............................2
2.1 Identification plate ..................................................3
2.2 CE-mark/conformity ...............................................3
2.3 Intended use .............................................................3
3 Safety instructions and regulations ............3
3.1 Safety instructions .................................................3
3.2 Regulations ...............................................................3
4 Fitting ...............................................................4
4.1 Scope of delivery ....................................................4
4.2 Accessories ...............................................................4
4.3 Assembling VR 60 mixer module ........................4
5 Electrical installation .....................................5
5.1 Connecting the mixer module to the
building ......................................................................5
5.2 Connecting the heating circuit as a
cylinder charging circuit (not with Vaillant
geoTHERM VW.. .../2 heat pump.) .......................6
5.3 Setting the Bus address ........................................7
6 Start-up ............................................................7
7 Technical data .................................................7
8 Warranty and customer service ...................8
8.1 Vaillant warranty.....................................................8
8.2 Vaillant service ........................................................8
1 Notes on the documentation
The following information is intended to help you
throughout the entire documentation.
Further documents apply in combination with this instal-
lation manual.
We accept no liability for any damage caused by fail-
ure to observe these instructions.
Other applicable documents
Observe the individual operating and installation manu-
als of the various components of the plant when install-
ing, commissioning and starting up.
Storage of the documents
Pass on this installation manual to the owner of the sys-
tem in order for him/her to store it so that it is available
whenever it is required.
Symbols used
Please observe the safety instructions in this installation
manual for the installation of the appliance.
The symbols used in the manual are explained below:
d
Danger!
Immediate risk of serious injury or death
e
Danger!
Danger of death by electric shock!
a
Caution!
Potentially dangerous situation for the product
and environment.
h
Note!
Useful information and instructions
• Symbol for a necessary task
Applicability of the instructions
These installation instructions apply exclusively to units
with the following part numbers:
– 306782
– 0020076591
The part number of the unit can be found on the identi-
fication plate.
2 Description of the device
The VR 60 mixer module is used for system expansion
of the auroMATIC 620 or VRC 630 controllers and
Vaillant geoTHERM VW.. .../2 heat pumps.
Up to a maximum of six mixer modules can be connect-
ed. Two additional mixer circuits can be controlled per
VR 60 mixer module.
