Main component 05 Gas section
VC 110,180,221,240 T, VCW 221,240,280 T H, B
Pict.
No.
Article-No. Part Indic. Type, Remarks
S = town gas, H = Natural gas, B = LP-gas
2 05-3073 gas section S,H
05-3076 gas section B
3 98-0831 packingring
4 05-0224 operator S,H
05-0167 operator B
5 21-9235 operating jet 19 M 110,180 H
21-9233 operating jet 16 M S, 180,221,240 H
21-9232 operating jet B
6 98-1504 packingring
7 21-8011 flow switch connection 110
08-4128 hose connection 180-280
8 08-0357 hose 145 mm
9 13-3702 screw
10 10-5782 screw
11 21-8013 flow switch connection 110
08-4127 hose connection 180,240,280
08-8930 flow switch connection 221
12 08-0358 hose 60 mm 110,180,240,280
13 49-2147 screw
28 20-4038 cap
29 07-1472 push button
30 12-6234 micro-switch
31 06-0018 screw
32 49-2112 disc
33 17-0295 magneto
34 98-2472 packingring
35 98-0842 packingring
36 19-5031 magneto housing
37 10-5758 screw
38 11-1459 disc
39 17-0025 locking plate
40 04-0364 nut
41 08-9526 connection line no longer required on VC-VCW 221 only, use part 17-1181
supplied with parts 3,4,13,28,30-40
supplied with parts 3,6
