Subject to alteration 39
Main component 05 Gas section
VC 112,142,182,242,282 E, VCW 242,282 E H, B
Pict.
No.
Article-No. Part Indic. Type, Remarks
S = town gas, H = Natural gas, B = LP-gas
1 05-3255 gas section S,H
05-3079 gas section B
2 05-0224 operator S,H
05-0167 operator B
3 05-0164 operator H (with part load device)
4 98-0831 packingring
5 21-9233 operating jet 16 M S
21-9235 operating jet 19 M H
21-9232 operating jet B
6 98-0224 packingring
7 21-8011 flow switch connection 112,142
08-4128 hose connection 182,242,282
8 08-0357 hose 145 mm
9 13-3702 screw
10 10-5782 screw
11 08-8947 flow switch connection 112,142
08-8930 flow switch connection 182,242,282
12 08-0358 hose 60 mm
08-0369 hose 255 mm
13 11-8948 screw
14 15-1017 pressure diff. switch
15-16 - - single delievery not possible, with part 15-1017
17 01-2156 stuffing box
18 98-0223 packingring
19 11-8947 screw
20 - diaphragm disc single delievery not possible, with part 15-1017
21 02-0220 diaphragm
22-27 - connection see main component 08
28 98-2490 packingring
29 15-4133 bow
40 10-5758 screw
supplied with parts 2,4,6,10,13-21
supplied with parts 4,6
