PART 1 CONCENTRIC 60/100
PLANNING THE AIR/FLUE DUCT LAYOUT
7
Fig. 1.7: Tiles for pitched roofs
Adjustable roof tile
Accy. No.: 9076
GU_LAZ 41/0
Fig. 1.6: Sliding sleeve, Ø 60/100
Sliding sleeve, Ø 60/100
Accy. No.: 303 816
LAS Euro B/S 016/0
Fig. 1.5: Flue support clip, Ø 100
Flue support clips, Ø 100 (Pack of 5)
Accy. No.: 303 821
GU_LAZ 72/0
☞ Use one clip per extension to
support the air/flue duct.
Fig. 1.8: Flat roof penetration collar
GU_LAZ 42/0
Flat roof penetration collar
Accy. No.: 9056
