Vaillant VRC 700f/4 User Manual

Notes on the documentation 2
0020237621_02 Operating instructions 5
2 Notes on the documentation
2.1 Observing other applicable documents
▶ You must observe all operating instructions enclosed with
the system components.
2.2 Storing documents
▶ Keep this manual and all other applicable documents
safe for future use.
2.3 Validity of the instructions
These instructions apply only to:
VRC 700f/4 – article number
Great Britain
0020231564
2.4 Nomenclature
The following terms are used for simplification:
– System control: This refers to the VRC 700f/4 wireless
system control.
– Remote control: This refers to the VR 91f wireless
remote control.
– Outdoor temperature sensor: This refers to the wireless
outdoor temperature sensor.
2.5 Function availability
The functions described in these operating instructions are
not available for all system configurations.
The system control only shows the functions that are avail-
able in the system configuration you have installed.
3 Product description
3.1 Design of the product
3.1.1 Radio receiver unit
4
3
1
2
1 Wall-mounting base
2 Diagnostics socket
3 LED status display
4 Teach-in button
3.1.2 Radio controller
2
1
3
2
5
6
4
1 Display
2 Selection button
3 Diagnostics socket
4 Battery compartment
5 Wall-mounting base
cover
6 Rotary knob
