3 Product description
6 Operating instructions vSMART 0020212889_01
3.1 Design of the product
6
4
5
9
7
8
210 1 3
1
and buttons
2 Small wall socket: Ther-
mostat
3 Wall socket: Communic-
ation unit
4 Bluetooth button/comfort
protection mode button
5 Status LED
6 Communication unit
7 Display
8 Thermostat
9 Product stand
10 Large wall socket:
Thermostat
3.2 Display
Symbol Meaning
Connection between the thermostat and
communication unit is being established
Connection has been established; nor-
mal operation
Connection has been broken
3.3 Information on the identification plate
The identification plate is mounted on the rear of the commu-
nication unit and the thermostat in the factory.
Information on the
identification plate
Meaning
Barcode with serial number (on the
communication unit only),
7th to 16th digit = product article number
→ "CE label" section
