User's Guide ________________________________________________________
20 _____________________________________________________M210185EN-C
NOTE
Even the smallest water drop on the probe near the sensors
distorts the readings. Make sure that chamber covers and
plugs are carefully closed.
0606-170
Figure 7 Salt chamber
The following numbers refer to Figure 7 above
1 =
HMP233 probe
2 = O-rings
3 = Sensors
4 = Max. 1 cm
5 = Thermometer
6 = Saturated salt solution
7 = Undissolved salt
