Val Controls IHP24-BF User Manual

DHP-UM-013
Val Controls A/S • Limfjordsvej 3 • DK-6715 Esbjerg N • Tel. +45 7547 0600 • Fax +45 7547 0611
vc@valcontrols.com • www.valcontrols.com
Revision: 4
27/58
Value: 1
Description: Internal communication settings
between Val Controls product and fieldbus
interface. Do not change
BAD_STATUS
[Others]
Bad Status
Value: 0
Description: Error Look up table
If a bit is high on of the MOD In/Out/D1/D1… If a
input / output has bad status, the bit would be set
here.
ERR_LOOK_SEL
[Others]
Err Look Select
Value: The Error register to monitor. Only for status
info
ERR_LOOK_RESULT
[Others]
Err Look Result
Value: The status of the monitored register. Only for
status info
MOD_IN1
[Others]
MOD_IN – Analog Input 1
Length: 4 bytes, Unsigned 16
Value: 0.00 – 100.00
Type: Position Value
Value Status: Good, Bad ..
Description: Analog Input from sensor
SCALE_LOC_IN1
[Others]
SCALE_LOC_IN
Value FROM_EU100 = 10000
Value FROM_EU0 = 0
Value TO_EU100 = 100
Value TO_EU0 = 0
Value Data Type = Unsigned16_10
Value Function Code = FC03 Read Holding
Register
Value REGISTER_ADDR_OF_VALUE = 7000
Value REGISTER_ADDR_OF_ STATUS = 7100
Description: Internal communication settings
between Val Controls product and fieldbus
interface. If input is not used set
REGISTER_ADDR_OF_STATUS = 0, Status sub
status then changes to “Out of Service”
MOD_IN2
[Others]
MOD_IN
Length: 4 bytes, Float
Value: 0.00 – 100.00
Value Status: Good, Bad ..
Description: Analog Input from sensor
SCALE_LOC_IN2
[Others]
SCALE_LOC_IN_2
Value FROM_EU100 = 10000
