Val Controls IHP24-BF User Manual

DHP-UM-013
Val Controls A/S • Limfjordsvej 3 • DK-6715 Esbjerg N • Tel. +45 7547 0600 • Fax +45 7547 0611
vc@valcontrols.com • www.valcontrols.com
Revision: 4
5/58
3 Specifications
3.1 Electrical specifications for standard configuration
FF-Fieldbus
Interface
FF-Fieldbus - H1 Device Class – Basic Device
Termination
No internal termination
Baud rate
31250 baud
Field bus ID (Node ID)
Node ID 17 – 36 and 223 - 247
Software selectable
Default Node ID 247
Default Tag Name
“Val Controls” can be changed.
Execution Time
- AI 25 ms
- AO 31.25 ms
- DI 25 ms
- DO 25 ms
- PID 31.25 ms
- RATIO 31.25 ms
- BG 25 ms
- SC 25 ms
- ISEL 25 ms
- LLAG 25 ms
PD_TAG = Modbus_FF
Manufacture Id = 0x000105 hex - Microcyber Inc
Device Type = 0x1001 hex
DEV-Rev = 0x01 hex
DD-Rev=0x01 hex
CF-Rev = 0x01 hex
ITK-Rev = 5.00
DD-File - Tested on the following systems
- Emerson Delta V version 8.4.2
- Yokogawa Centum VPR 5.01
- Honeywell, Experion control system revision 400.2
3.2 Power Ratings
FF-Fieldbus – H1
Power Requirements: 9-32 V
Current Consumption: < 5mA
