Value TO_EU100 = 10000
Value TO_EU0 = 0
Value Data Type = Unsigned16_10
Value Function Code = FC16 Write Multiple
Register
Value REGISTER_ADDR_OF_VALUE = 7010
Value REGISTER_ADDR_OF_STATUS = 7110
Description: Internal communication settings
between valcontrols product and fieldbus interface.
Value and status send from Fieldbus function and
send down into Val Controls Unit. Value can also
be scaled.
MOD_OUT2
[Others]
Same as MOD_OUT1
SCALE_LOC_OUT2
[Others]
Same as SCALE_LOC_OUT1
Value REGISTER_ADDR_OF_VALUE = 7011
Value REGISTER_ADDR_OF_STATUS = 7111
MOD_OUT3
[Others]
Same as MOD_OUT1
SCALE_LOC_OUT3
[Others]
Same as SCALE_LOC_OUT1
Value REGISTER_ADDR_OF_VALUE = 7012
Value REGISTER_ADDR_OF_STATUS = 7112
MOD_OUT4
[Others]
Same as MOD_OUT1
SCALE_LOC_OUT4
[Others]
Same as SCALE_LOC_OUT1
Value REGISTER_ADDR_OF_VALUE = 7013
Value REGISTER_ADDR_OF_STATUS = 7113
MOD_OUT5
[Others]
Same as MOD_OUT1
SCALE_LOC_OUT5
[Others]
Same as SCALE_LOC_OUT1
Value REGISTER_ADDR_OF_VALUE = 7014
Value REGISTER_ADDR_OF_STATUS = 7114
MOD_OUT6
[Others]
Same as MOD_OUT1
SCALE_LOC_OUT6
[Others]
Same as SCALE_LOC_OUT1
Value REGISTER_ADDR_OF_VALUE = 7015
Value REGISTER_ADDR_OF_STATUS = 7115
MOD_OUT7
[Others]
Same as MOD_OUT1
SCALE_LOC_OUT7
[Others]
Same as SCALE_LOC_OUT1
Value REGISTER_ADDR_OF_VALUE = 7016
Value REGISTER_ADDR_OF_STATUS = 7116
MOD_OUT8
[Others]
Same as MOD_OUT1
SCALE_LOC_OUT8
[Others]
Same as SCALE_LOC_OUT1
Value REGISTER_ADDR_OF_VALUE = 7017
Value REGISTER_ADDR_OF_STATUS = 7117
MOD_IN_D1
[Others]
MOD_IN_D1
Length: 1 bytes
1: Value: 0 to 255 Read from Sensor
2: Status - Quality: Good, Bad ..
