4.2 Digital input – DI13, DI14
DI13 substitutes AI1 and DI14 substitutes AI2.
Switch
-
DI
+
+ -
1kΩ ½W
The external resistor must be mounted to get the correct functionality.
4.2.1 Terminals
DI13
11 (+)
12 (-)
DI14
13 (+)
14 (-)
4.2.2 Electrical specification
DI13, DI14, DI15, DI16, DI17
Type
Switch
Cable length
1000 meters
