valent VPR Series User Manual

Valent Controls IOM 30 IOM-C1-0616
Part Number 474626
Description
UMT Name
 = Editable
LCD Name
 = Editable
Web UI Name
 = Editable
Min
Max
Default
States
CO2 Enabled
Control Enabled
INSTALLED
Enable CO2 Control
—
—
—
Not Installed, Installed
CO2 Level
CO2 Level
CO2 LEVEL
—
0 ppm
2,000 ppm
—
—
CO2 Setpoint
CO2 Setpoint
SETPOINT
CO2 Setpoint
0 ppm
2,000 ppm
900 ppm
—
Compressor 1 Ambient Lockout
Setpoint
Compressor 1 Ambient Lockout
Setpoint
—
Comp #1 Lockout Setpoint
40.0°F
90.0°F
55°F
—
Compressor 1 Output
Compressor 1 Output
COMP 1
Compressor 1
—
—
—
Off, On
Compressor 2 Ambient Lockout
Setpoint
Compressor 2 Ambient Lockout
Setpoint
—
Comp #2 Lockout Setpoint
40.0°F
90.0°F
55°F
—
Compressor 2 Output
Compressor 2 Output
COMP 2
Compressor 2
—
—
—
Off, On
Compressor 3 Ambient Lockout
Setpoint
Compressor 3 Ambient Lockout
Setpoint
—
Comp #3 Lockout Setpoint
40.0°F
90.0°F
55°F
—
Compressor 3 Output
Compressor 3 Output
COMP 3
Compressor 3
—
—
—
Off, On
Compressor 4 Ambient Lockout
Setpoint
Compressor 4 Ambient Lockout
Setpoint
—
Comp #4 Lockout Setpoint
40.0°F
90.0°F
55°F
—
Compressor 4 Output
Compressor 4 Output
COMP 4
Compressor 4
—
—
—
Off, On
Cooling Execution Time
Cooling Execution Time
—
—
0
100
0.5
—
Cooling Integral Constant
Cooling Integral Constant
—
—
0
100
0.5
—
Cooling Proportional Constant
Cooling Proportional Constant
—
—
0
100
3
—
Damper Configuration
Damper Configuration
DAMPER CONFIG
—
—
—
—
100% OA, Recirc
Damper Output
Damper Output
OA DAMPER
OA Damper Position
0%
100%
—
—
Damper Remote Control
Damper Remote Control
—
Remote Damper Enabled
—
—
—
Enabled, Disabled
Defrost Mode
Defrost Mode
DEFROST MODE
Defrost Mode
—
—
—
Normal, Defrost
Dehumidification Priority
Dehumidification Has Priority
—
Dehumidification Priority
—
—
Yes
No, Yes
Dehumidification Status
Dehumidification Status
DEHUM STATUS
—
—
—
—
False, True
Digital/Chilled Water Output
Digital/Chilled Water Output
CHW/DIGITAL OUT
Digital Output
0%
100%
—
—
Duct Pressure
Duct Pressure
PRESSURE
Duct Pressure
0 InWc
5 InWc
—
Duct Pressure High Limit
Setpoint
Duct Pressure High Limit
Setpoint
HIGH LIMIT
Duct Pressure High Limit
0 InWc
5 InWc
2.50 InWc
—
Duct Pressure Setpoint
Duct Pressure Setpoint
SETPOINT
Duct Pressure Setpoint
0 InWc
5 InWc
1.00 InWc
—
DX Coil Leaving Temperature
DX Coil Leaving Temperature
DX COIL TEMP
DX Coil Temperature
-13°F
326°F
—
—
DX Coil Low Limit Safety
DX Coil Low Limit Safety
—
Coil Safety Limit
35°F
55°F
46°F
—
DX Coil Low Limit Setpoint
DX Coil Low Limit Setpoint
—
Coil Low Limit
35°F
45°F
42°F
—
DX Coil Setpoint
DX Coil Setpoint
DX COIL SETPT
DX Coil Setpoint
50°F
80°F
55°F
—
Economizer Configuration
Economizer Configuration
—
—
—
—
Outdoor
Temper-
ature
Comparative Enthalpy,
Outdoor Enthalpy,
Outdoor Temperature
Economizer Enable Setpoint
Enthalpy
Economizer Enable Setpoint
Enthalpy
ENTHALPY SPT
Econ Setpoint Enthalpy
15 Btu/lb
40 Btu/lb
23 Btu/lb
—
Economizer Enable Setpoint
Temperature
Economizer Enable Setpoint
Temperature
DRY BULB SPT
Econ Setpoint Temp
50°F
90°F
60°F
—
Electric Heat Output
Electric Heat Output
ELECTRIC
Electric Output
0%
100%
—
—
Enable Compressor 1 Ambient
Lockout
Enable Compressor 1 Ambient
Lockout
—
Comp #1 Lockout Enable
—
—
No
No, Yes
Enable Compressor 2 Ambient
Lockout
Enable Compressor 2 Ambient
Lockout
—
Comp #2 Lockout Enable
—
—
No
No, Yes
Enable Compressor 3 Ambient
Lockout
Enable Compressor 3 Ambient
Lockout
—
Comp #3 Lockout Enable
—
—
No
No, Yes
Enable Compressor 4 Ambient
Lockout
Enable Compressor 4 Ambient
Lockout
—
Comp #4 Lockout Enable
—
—
No
No, Yes
Enable Occupancy Auto Mode
Enable Occupancy Auto Mode
—
Enable Occ Auto
—
—
Occ On
Occ Auto, Occ On
Enable Winter Ramp
Enable Winter Ramp
—
Winter Ramp
—
—
True
False, True
Exhaust Air Temperature
Exhaust Temp
EXHAUST TEMP
Exhaust Temperature
-13°F
326°F
—
—
Exhaust Fan Configuration
Configuration
—
—
—
—
—
None, Supply Tracking,
EF Space Pressure,
EF Hardwired, EF BAS Control
Exhaust Fan Enable Damper
Position
Exhaust Fan Enable Damper
Position
EX FAN DAMP POS
Exhaust Damper Enable
0%
100%
15%
—
Exhaust Fan Maximum Speed
Exhaust Fan Max Speed
EX FAN MAX SPEED
Exhaust Max Speed
25%
100%
100%
—
Exhaust Fan Minimum Speed
Exhaust Fan Min Speed
EX FAN MIN SPEED
Exhaust Min Speed
25%
100%
25%
—
Exhaust Fan Offset
Exhaust Fan Offset
EX SPEED OFFSET
Exhaust Fan Offset
-20%
20%
0%
—
Exhaust Fan Output
Exhaust Fan Output
EXH FAN
Exhaust Fan
—
—
—
Off, On
Exhaust Fan Reaction Speed
Exhaust Fan Reaction Speed
EXHAUST
REACTION
Exhaust Static Reaction
—
—
Medium
Very Slow, Slow, Medium,
Fast, Very Fast
