Valent Controls IOM 31 IOM-C1-0616

Part Number 474626

Description

UMT Name

 = Editable

LCD Name

 = Editable

Web UI Name

 = Editable

Min

Max

Default

States

Exhaust Fan Speed

EXH FAN SPEED

Exhaust Fan Speed

100%

—

Exhaust Fan Status

EXH FAN STATUS

Exhaust Fan Status

—

Off, On

Flat Pate Defrost Setpoint

Flat Plate Exhaust Defrost

—

Flat Plate Defrost

15°F

60°F

38°F

—

Furnace Ramp Limit 1

—

100%

60%

—

Furnace Ramp Limit 2

—

100%

80%

—

Furnace Ramp Release Delay

Ramp Release Delay

—

0 min

20 min

5 min

—

Furnace Ramp Release Temp 1

—

-20°F

60°F

20°F

—

Furnace Ramp Release Temp 2

—

-20°F

60°F

0°F

—

Furnace Supply Fan Limit Offset

Supply Fan Furnace Limit Offset

—

-20%

20%

—

Gas Heat Stage 1 Output

Stage 1

STAGE 1

Furnace 1

—

Off, On

Gas Heat Stage 2 Output

Stage 2

STAGE 2

Furnace 2

—

Off, On

Gas Heat Stage 3 Output

Stage 3

STAGE 3

Furnace 3

—

Off, On

Head Pressure Control Analog

Output 1

Head PR Output 1

HEADPRESSURE

Cond Fan Speed

100%

—

Head Pressure Control Digital

Output 2

Head PR Output 2

HEADPRESSURE

Head Pressure Output

—

On, Off

Heat Pump Water Valve A

Output

Valve A Output

VALVE A OUTPUT

Heat Pump Vlv A

100%

—

Heat Pump Water Valve B

Output

Valve B Output

VALVE B OUTPUT

Heat Pump Vlv B

100%

—

Heat Wheel Defrost Setpoint

Heat Wheel Exhaust Defrost

—

Heat Wheel Defrost

15°F

60°F

36°F

—

Heat Wheel Jog Duty Cycle

HW Jog Duty Cycle

—

100%

10%

—

Heat Wheel Jog Period

HW Jog Period

—

Heat Wheel Operating Mode

—

On When

Econo-

mizing

Off When Economizing,

On When Economizing,

Always On

Heat Wheel Output

WHEEL OUTPUT

Heat Wheel

—

Off, On

Heat Wheel Speed / Bypass

Damper Position

Heat Wheel Speed/Damper

Position

ENERGY RECOV

Energy Recovery

100%

—

Heat Wheel Speed When

Economizing

HW Speed When Economizing

—

8.5%

30%

17%

—

Heat Wheel Status

WHEEL STATUS

Heat Wheel Status

—

Rotating, Stopped

Heating Execution Time

—

100

0.5

—

Heating Integral Constant

—

100

0.5

—

Heating Proportional Constant

—

100

1.75

—

High/Low Pressure Trip

Shutdown Unit if Circuits Tripped

High/Low Pressure Trip

Shutdown Circuit

—

Unit Shutdown Circuit

—

All Tripped

All Tripped, Any Tripped

High/Low Pressure Trips

Shutdown Unit

Shutdown Unit During High/Low

Pressure Trip

—

High/Low Pressure Trip

—

No, Yes

Hot Water Case Heat Outside

Temperature Enable

Hot Water Case Heat Outside

Temp Enable

HW CASE HEAT

ENABLE

OAT Enable

-20°F

120°F

35°F

—

Hot Water Case Heat Setpoint

HW CASE HEAT SPT

Case Temp

35°F

50°F

40°F

—

Hot Water Valve Position When

Unit Off

Hot Water Valve Off Position

—

Modulating

Open, Closed, Modulating

Mixed Air Temperature

MIXED AIR TEMP

Mixed Air Temperature

-13°F

326°F

—

Modulating Heat Output

MODULATING

Modulating Output

100

—

Morning Warm Up Enable

Enable

ENABLE

—

Disabled

Enabled, Disabled

Morning Warm Up Status

WARM UP STATUS

Warm Up Mode

—

Inactive, Active

Morning Warm Up Type

Morning Warm Up

—

None, Installed

Night Purge Enable

—

Night Purge Enable

—

Disabled

Enabled, Disabled

Night Purge Type

Night Purge

—

None, Installed

Occupancy Controlled By

Occupied By

OCC BY

Occupied By

—

Unoccupied, External Input,

Schedule, Optimal SS,

BAS, Timed Override

Occupancy Schedule

System Schedule

SCHEDULE

Occ Schedule

—

24/7

—

Occupancy Status

OCC STATUS

Occupancy Mode

—

Unoccupied Off, Unocc

Cooling, Unocc Heating,

Unocc Dehum, Unoccupied

On, Occupied Auto, Shutdown

Optimal Start Enable

Enable Optimal Start

—

Enable Optimal Start

—

No, Yes

Optimal Start/Stop Earliest Start

Time

Earliest Start Time

—

Earliest Start Time

0 hr

24 hr

6 hr

—
