Technical specifications
Model
VMC-3
VMC-3 Turbo
Voltages
V
3N400
3N230
1N240
3N400
Rating
KW
6.6
6.6
7.2
10
Connection
A
9.5
28.7
30
14.45
Frequency
Hz
50/60
Capacity in litres
L
35-40
Principal switch
1
Service thermostat 40-105°C
1
Safety thermostat
1
Protection factor
IP X4
Pan
510 / 308 / 310
Ball drain valve
G¾ ‘’
Installation
Important precautions for installation
 The purchaser must have the Multicooker installed at his own cost by an approved dealer
in accordance with local regulations.
 The voltage, frequency and current should comply with the information given on the rating
plate on the Multicooker.
 The Multicooker should in any case be connected to safety earth by the mains lead. The
Multicooker is supplied with a mains cable 1,9 m in length.
 Conductor colours:
Earth : yellow / green Neutral : blue
 Before connecting up, set switch [2] to « 0 ».
 Never switch the Multicooker on without water, otherwise the elements can be damaged.
 Before switching on, make sure there is water in the pan at least up to the "MIN" level
mark. Do not fill past the "MAX" mark to prevent overflow.
Connection of drainage tube
The drain tube size is G3/4" [2]
Connector : nipple G3/4" x 60mm
Ways of draining
Container : under the tap
Connection with the waste system according to current regulations
Pipe with connection G3/4"
Flexible pipe Ø25 mm and clamp
In the even of connection with the flow use the overflow pipe [15] in the inside of the
pan to maintain a constant level.
After Sales intervention
The box protecting [17] the connector block of the heating element must always remain in
place.
