CC 140S - CC 150S - CC 160S - CC 160WCT MPHE - CC 165W - CC 165WCT MPHE - CC 175W - CC 175WCT MPHE
2- Technical data sheet
EQUIPMENT DESCRIPTION
Model CC140S CC150S CC160S CC165W CC175W CC160WCT MPHE CC165WCT MPHE CC175WCT MPHE
Cooling capacity
40.000 BTU/h
(11,5kW)
50.000 BTU/h
(14,5kW)
60.000 BTU/h
(17,5kW)
65.000 BTU/h
(19kW)
75.000 BTU/h
(21kW)
60.000 BTU/h
(17,5kW)
65.000 BTU/h
(19kW)
75.000 BTU/h
(21kW)
Type R134a R134a R134a R134a R134a R134a R134a R134a
Quantity 2,0 Kg 2,5 Kg 3,0 Kg 3,5 Kg 3,5 Kg 2,0 Kg 2,5 Kg 2,5 Kg
Model of blowers Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal
Quantity of blowers
2 2 2 3 3 2 3 3
Air flow (free blowing) 2.740 m³/h 2.740 m³/h 2.740 m³/h 3.210 m³/h 3.210 m³/h 2.740 m³/h 3.210 m³/h 3.210 m³/h
32A / 18A 32A / 18A 32A / 18A 48A / 27A 48A / 27A 32A / 18A 48A / 27A 48A / 27A
Model of fans Axial Axial Axial Axial Axial Axial Axial Axial
Quantity of fans
2 2 2 2 3 1 2 2
Air flow (free blowing) 4.800 m³/h 4.800 m³/h 4.800 m³/h 4.800 m³/h 7.200 m³/h 2.900 m³/h 5.800 m³/h 5.800 m³/h
Nominal current
32A / 18A 32A / 18A 32A / 18A 32A / 18A 48A / 27A 32A / 18A 32A / 18A 32A / 18A
Model (alternative type) SP16 SP16 SP22 SP22 SP32 SP22 SP22 SP32
Displacement
163 cm³ 163 cm³ 212 cm³ 212 cm³ 313 cm³ 212 cm³ 212 cm³ 313 cm³
Maximum allowed rotation
6.000 RPM 6.000 RPM 4.500 RPM 4.500 RPM 4.500 RPM 4.500 RPM 4.500 RPM 4.500 RPM
Compressor quantity
150 ml 150 ml 180 ml 180 ml 500 ml 180 ml 180 ml 500 ml
Amount added
without Defroster
250 ml 350 ml 400 ml 500 ml 200 ml 500 ml 500 ml 200 ml
Amount added
with Defroster
350 ml 450 ml 500 ml 600 ml 300 ml 600 ml 600 ml 300 ml
Type Electromagnetic Electromagnetic Electromagnetic Electromagnetic Electromagnetic Electromagnetic Electromagnetic Electromagnetic
Electric tension 12V / 24V 12V / 24V 12V / 24V 12V / 24V 12V / 24V 12V / 24V 12V / 24V 12V / 24V
Lubricating
oil
027-00001-000
CONDENSER
CLUTCH
AIR
CONDITIONING
COOLING GAS
EVAPORATOR
COMPRESSOR
