EQUIPMENT DESCRIPTION
3.1- Condenser Components
12
2
5
4
8
9
3
10
11
CC 646 MS - CC 676 MS
13
ITEM DESCRIPTION QTY.
1 Condenser Central Closing 1
2 Extruded Aluminum C Profile 1
3 Extruded Aluminum C Profile 1
4 Condenser Coil 1
5 Axial 24V 12" Electronic Condenser Fan 6
6 Discharge Pipe Set 1
7 Front Finish Cover 1
8 Condenser Liquid Line Set 1
9 Liquid Tank / Drier Filter 1
10 Tank Liquid Line Set 1
11 Finishing Rubber 2
12 Condenser / Evaporator Base w/ Renewall 1
13 Condenser Electric Wiring Harness 1
