PROGRAMMING OPTIONS (System One w/VR102 Board Only)
In Program mode System One room stations can have the following options programmed:
6 Wire or 8 Wire operation (Installer option)
Single digit or double digit operation for Select Calls (Installer option)
Keypad back lighting - on or off (User option)
Station coding (User option)
Enter Program mode
Enter programming mode by pressing the “PRIVACY” and “MONITOR” buttons simultaneously.
6 Wire / 8 Wire Mode
This setting is determined by how the system has been wired.
Green LED off indicates 6 Wire and Green LED on indicates 8 Wire
Pressing house button toggles between 6 Wire and 8 wire modes
NOTE: This setting is usually set by the installer and should not be altered.
Single digit and Double digit Select Calling
Single digit Select Calling is designed for systems requiring up to 8 select call channels.
Double digit Select Calling is designed for systems requiring from 9 to 20 select call channels.
Single digit numbers are displayed as a series of 1 to 8 repeated flashes
Double digit numbers are displayed by 2 quick flashes (indicating Double digit mode)
followed by 1 to 3 flashes (indicating the first digit) followed by 1 to 8 flashes
(indicating the second digit)
The Auxiliary button is used to toggle between Single Digit & Double Digit modes
NOTE: This setting is usually set by the installer and generally should not be altered.
Keypad Backlighting
Keypad illumination can be toggled on or off using the Door button.
