34
Specifications
Operating Frequencies: 10.500 – 10.550 GHz (X band)
24.050 – 24.250 GHz (K band)
33.4 – 36.0 GHz (Ka band)
13.400 – 13.500 GHz (Ku band): not used in U.S. —
to activate Ku band, see www.valentine1.com
(Ask Mike, Tech Reports, Report 3), or
http://www.valentine.com/lab/MikesLabRpt3.asp.
820-950 nanometers (Laser)
Power Requirements: 11.0-16.0 Volts DC negative ground
225 mA typical standby, 425 mA maximum
alarm condition
Dimensions and Weight: 4.5 in. L x 3.6 in. W x 1.0 in. H; 6.4 ounces
114.3 mm L x 91.4 mm W x 25.4 mm H; 181 grams
Temperature Range: Operating: -20˚C to +70˚C (-4˚F to +158˚F)
Storage: -30˚C to +85˚C (-22˚F to +185˚F)
