Valley Classic Control Panel
Operation
Percent Timer Setting Calculation Worksheet (Continued)
100% = (_____) Inches(millimeters)/Per Revolution
90% = (_____) ÷ (0.90) = ______ In (mm)/Rev
80% = (_____) ÷ (0.80) = ______ In (mm)/Rev
70% = (_____) ÷ (0.70) = ______ In (mm)/Rev
60% = (_____) ÷ (0.60) = ______ In (mm)/Rev
50% = (_____) ÷ (0.50) = ______ In (mm)/Rev
40% = (_____) ÷ (0.40) = ______ In (mm)/Rev
30% = (_____) ÷ (0.30) = ______ In (mm)/Rev
25% = (_____) ÷ (0.25) = ______ In (mm)/Rev
20% = (_____) ÷ (0.20) = ______ In (mm)/Rev
15% = (_____) ÷ (0.15) = ______ In (mm)/Rev
10% = (_____) ÷ (0.10) = ______ In (mm)/Rev
5% = (_____) ÷ (0.05) = ______ In (mm)/Rev
100% = (_____) Hours Per Revolution
90% = (_____) ÷ (0.90) = ______ Hrs/Rev
80% = (_____) ÷ (0.80) = ______ Hrs/Rev
70% = (_____) ÷ (0.70) = ______ Hrs/Rev
60% = (_____) ÷ (0.60) = ______ Hrs/Rev
50% = (_____) ÷ (0.50) = ______ Hrs/Rev
40% = (_____) ÷ (0.40) = ______ Hrs/Rev
30% = (_____) ÷ (0.30) = ______ Hrs/Rev
25% = (_____) ÷ (0.25) = ______ Hrs/Rev
20% = (_____) ÷ (0.20) = ______ Hrs/Rev
15% = (_____) ÷ (0.15) = ______ Hrs/Rev
10% = (_____) ÷ (0.10) = ______ Hrs/Rev
5% = (_____) ÷ (0.05) = ______ Hrs/Rev
Hours Per Revolution =
(Hours/Revolution at 100%) (100)
___________________________
(Percent Timer Setting)
= ( ) (100)
____________
( )
= ( )
________
( )
= _______
Inches (millimeters) Per Revolution =
(Inches(mm)/Revolution at 100%) (100)
_______________________________
(Percent Timer Setting)
= ( ) (100)
____________
( )
= ( )
________
( )
= _______
6. Determine Inches (millimeters) Per Revolution and Hours Per Revolution for any
percent timer setting using these two formulas:
