Repair Parts List
WARNING
DO NOT TOUCH THE BARRIER SCREEN OR
DO NOT TOUCH THE BARRIER SCREEN OR
FIREPLACE WHILE THEY ARE HOT!
FIREPLACE WHILE THEY ARE HOT!
Let the
fi replace cool fi rst before cleaning it.
fi replace cool fi rst before cleaning it.
FOR SAFETY PURPOSE, ensure the barrier
FOR SAFETY PURPOSE, ensure the barrier
screen is re-installed on the fi replace front after
screen is re-installed on the fi replace front after
maintenance if it has been removed.
maintenance if it has been removed.
WARNING
!
7. Install the barrier screen. The tabs rest at the
bottom and the screen is held in place by magnets.
a. Rest the bottom tabs on the edge of the plinth as
indicated.
b. Push the screen against the steel front panel.
Maintenance
To clean the trim, use mild soap and water. To clean
the screen, dust it with a soft brush.
To clean the window and ceramics inside the fi rebox,
consult the Owner’s Information section of the
Installation and Owner’s Manual supplied with the
fi replace.
DO NOT CLEAN THE GLASS WINDOW WITH
AMMONIA!
6
5
4
3
1
2
Code Description Part Number
1 Linerbox bracket 4004861
2 4-Sided front plate 4004853AZ
3 LH door assembly 4004535AZ
4 RH door assembly 4004536AZ
5 Plinth 4005827AZ
6 Barrier screen assy 4005630
not shown
#8 x 1/2 s/t screws black (4) 4004560
a
a
b
tabs at the
bottom
