VENTING PARTS CODE / AVAILABILITY BY MANUFACTURER
VENTING PARTS
DESCRIPTION
SIMPSON
DURAVENT
SELKIRK
SECURE
VENT
RLH
INDUSTRIES
MILES
INDUSTRIES
Galvanized
945
Black
945B SV4EBR45
Galvanized Swivel
945G 4DT-EL45 SV4E45
DV 45°
ELBOWS
Black Swivel
945BG 4DT-EL45(B)
SV4EB45
Galvanized
990
Black
990B SV4EBR90
Galvanized Swivel
990G 4DT-EL90 SV4E90
DV 90°
ELBOWS
Black Swivel
990BG 4DT-EL90(B)
SV4EB90
Galvanized
908 4DT-06 SV4L6
6" LONG
Black
908B 4DT-06(B)
SV4LB6
Galvanized
907 4DT-09
9" LONG
Black
907B 4DT-09(B)
Galvanized
906 4DT-12 SV4L12
12" LONG
Black
906B 4DT-12(B)
SV4LB12
Galvanized
4DT-18
18" LONG
Black
4DT-18(B)
Galvanized
904 4DT-24 SV4L24
24" LONG
Black
904B 4DT-24(B)
SV4LB24
Galvanized
903 4DT-36 SV4L36
36" LONG
Black
903B 4DT-36(B)
SV4LB36
Galvanized
902 4DT-48 SV4L48
PIPES 4" x 6 5/8" ( ID x OD )
48" LONG
Black
902B 4DT-48(B)
SV4LB48
ROOF FLASHING
0/12-6/12
943 4DT-AF6 SV4FA
ROOF FLASHING
7/12-12/12
943S 4DT-AF12 SV4B
FLASHINGS
FLAT ROOF FLASHING
943F SV4F
WALL THIMBLE
942 4DT-WT SV4RSM
STORM COLLAR
953 4DT-SC SV4AC
DECORATIVE PLATE
940 4DT-CS SV4PF
CATHEDRAL CEILING
SUPPORT
941 4DT-CCS
SV4BF
CEILING FIRESTOP/ FLOOR
SUPPORT
963 4DT-FS
SV4SD
WALL STRAP
988 4DTWS
VINYL SIDING STANDOFF
950 4DT-VS SV4VS
ELBOW STRAP
989 4DT-OS
VARIOUS VENTING SYSTEM
PARTS
TERMINAL GUARD
984SG 835TG
NOTES: 1) SIMPSON DURA-VENT CO-AXIAL PIPE AND FITTINGS REQUIRE VALOR 817VAK STARTER ADAPTER TO FIT
VALOR SMOOTH COLLARS. ALL OTHER ABOVE MANUFACTURERS' COLLARS WILL FIT DIRECTLY TO SIMPSON DURA-VENT
OR VALOR SMOOTH COLLAR; 2) FOLLOW INSTRUCTIONS PACKAGED WITH EACH MANUFACTURER'S COMPONENTS.
3) UNLESS OTHERWISE SPECIFIED, ALL THE PARTS AND ASSEMBLIES FROM THE ABOVE TABLE ARE TO BE USED
WITH 4" x 6-5/8" PIPES; 4) TERMINATION CAPS MANUFACTURED BY RLH INDUSTRIES ARE FROM HOMESTYLE CHIMNEY
COLLECTION AND CAN BE ORDERED IN ONE OF THE FOLLOWING FINISHES: a) ALUMINIUM; b) BLACK POWDER COATED;
c) SOLID COPPER.
