CONTENTS
Section Page
INSTALLER GUIDE 4 - 44
OWNER GUIDE 45 - 64
1. APPLIANCE DIMENSIONS 8
2. SAFETY 9
3. THE BENCHMARKING SCHEME 10
4. APPLIANCE DATA, EFFICIENCY AND NOx 11
4.1 General information. 11
4.2 Efficiency. 12
4.3 NOx 12
4.4 Accessories 12
5. GENERAL INSTALLATION REQUIREMENTS 13
5.1 Regulations, Standards and Law. 13
5.2 Ventilation requirements. 13
5.3 The Atmosphere sensing device (ASD). 14
5.4 Fireguard requirements. 14
5.5 Room considerations. 14
5.6 Chimney preparation. 14
5.7 Fireplace preparation. 14
5.8 The fireplace. 15
5.9 Fireplace clearances. 15
5.10 Installation options. 16 - 17
5.11 Flues. 17
6. PACK CONTENTS 18 - 19
7. FIREPLACE CHECK 20
7.1 Soundness for appliance attachment. 20
7.2 Fireplace flue pull. 23
8. GAS SUPPLY CONNECTION 20
9. PREPARING APPLIANCE FOR INSTALLATION 21 - 22
10. IGNITION CHECK 23
10.1 Fitting batteries to the remote control handset (RC) 23
10.2 Fitting batteries to the battery box (RC) 23
10.3 Setting the handset and receiver relationship (RC) 24
10.4 Checking the ignition operation (RC) 24
10.5 Fitting slider handle to control cam (FS) 25
10.6 Fitting the battery into spark ignition generator (FS) 25
10.7 Checking the ignition operation 25
Continued on next page
Page 5
© GDC Group Ltd. NOV 2017
