25 BREZZA60 INSTRUCTION AND MAINTENANCE MANUAL
1.5.2 Connection of an external power cord
Connection instructions
1) Break the plastic flaps.
2) Extract the terminal box from the internal
wall-mounting part and let the cables pass through the
dedicated space, fix the power cord with the screws
provided.
5
EXT
INT
6
4i
3) Fix the internal wall-mounting part (4i) to the wall and
make the electrical connections as described in the next
paragraphs.
