17. Loosen the retaining clamp ((arrow)) for the
hose connecting the suction tube to the
hydraulic pump oil fil ter, on the filter.
Disconnect the hose.
GUID-9DF705B3-EED4-410B-9221-679CC9202AE4-high.jpg [High]
Fig. 22
18. Disconnect the connector attaching the rear
wiring harness to the main harness ((arrow)),
next to the electrical panel.
GUID-A7BBA694-153F-417D-A671-6422856D207E-high.jpg [High]
Fig. 23
19. Disconnect the electrical connector ((arrow))
for the fuel sensor, underneath the front
floor.
GUID-F477518A-AAC5-4143-B481-D4FA3063F621-high.jpg [High]
Fig. 24
1. Introduction
1-35
ACX2831410
