Step9. Install the extended servo arm using two M2
x 6mm self-tapping screws.
Step10. Install a push rod connector to the servo
arm.
Step11. Install two aileron servos as shown using
hot glue.
Step12. Install elevator servo and rudder servo
onto the fuselage using hot glue. (the rudder servo
arm’s direction is toward to left, and the elevator
servo arm’s direction is toward to right.)
Step13. Glue the wood motor mount to the
fuselage.
Step14. Slide the horizontal fuselage into the
vertical fuselage. Align the tabs from the vertical
fuselage into the slots in the horizontal fuselage.
Adjust the vertical fuselage to make it in the center
line of the horizontal fuselage.
