9
Step15. Cut a slot on the aileron for the control
horn and Install an aileron control horn.
Step16. Install the rudder control horn and elevator
control horn.
(The slots for rudder and elevator control horn are
pre-cut.)
Step17. Install the tail skid (92mm long carbon
fiber strip).
Step18. Prepare the landing with two wheels
installed.
Step19. Insert the landing gear to the mount, and
install a M2 x 12mm self-tapping screw to secure
the landing gear.
