7 Technical data
V121/EN M/A017
17
7. Technical data
Auxiliary voltage
U
AUX
24V dc from the MINI-PS
In (stby)
30mA
IsensAct
20mA
Iarc
120mA + (IsensAct x n);
n = number of active sensors
Tripping contacts
Number
1
Rated voltage
250V ac/dc
Continuous carry
5A
Make and carry for 0.5s
30A
Make and carry for 3s
15A
Breaking capacity DC, when time constant
L/R=40ms
50W
Contact material
AgCdO2
Operating time
9ms
BIO Input / Output
Rated voltage
+24V dc
Rated current / output
20mA (max)
Rated current / input
5 mA
Number of inputs
1
Number of outputs
1
Disturbance tests
EMC test
CE approved and tested according to EN
50081-2, EN 50082-2
Emission
- Conducted (EN 55011 class A)
0.15 – 30 MHz
- Emitted (EN 55011 class A)
30 – 1 000 MHz
Immunity
- Static discharge (ESD) (According to
IEC244-22-2 and EN61000-4-2, class III)
Air discharge 8 kV
Contact discharge 6 kV
- Fast transients (EFT) (According to
EN61000-4-4, class III and IEC801-4, level 4)
Power supply input 2kV, 5/50ns
other inputs 2 kV, 5/50ns
- Surge (According to EN61000-4-5 [09/96],
level 4)
Between wires 2 kV / 1.2/50µs
Between wire and earth 4 kV / 1.2/50µs
- RF electromagnetic field test (According to
EN 61000-4-3, class III)
f = 80 – 1000 MHz 10V /m
- Conducted RF field (According to
EN 61000-4-6, class III)
f = 150 kHz – 80 MHz 10V
