7
SEAT TUBE ASSEMBLY
CARB O N
CARB O N
1 2 3
SEATPOST ADJUSTMENTS
5
10 N.M
5
4 N.M
ROUTING HOSES
FREIN AVANT FREIN ARRIÈRE
ROUTING DI2
2X EW-SD50
EW-AD305
EW-JC130
SM-JC41
FORK ASSEMBLY - BASE BAR
4
2 N.M
4
5 N.M
GREASE
MEDIUM THREAD LOCK
6
4 N.M
1 2
3 4
GR EAS E
Hose foam
