SPECIFICATIONS
TECHNICAL SPECS
HDMI Compliance ...................................................... HDMI Deep Color 30/36/48 bit color depth, Full 3D
HDCP Compliance ...................................................... Yes
Video Bandwidth ........................................................ Single-link 165MHz [4.95Gbps]
Video Support ........................................................... 480i/480p/720p/1080i/1080p @60
HDMI over UTP .......................................................... Full HD [1080P]-50m [165ft]; HD [720p/1080i]-
80m [262ft]
Audio Support ........................................................... Surround Sound (up to 7.1 ch) or stereo digital audio
Input TMDS Signal ..................................................... 1.2 Volts (peak to peak)
Input DDC Signal ........................................................ 5 Volts (peak to peak, TTL)
ESD protection .......................................................... (1) Human body model +/- 6kV (air-gap discharge) &
(contact discharge) (2) Core chipset - +/-8KV
PCB stack-up ............................................................ 4 layer board (impedance control - differential 100,
single 50
IR pass-thru .............................................................. Full-duplex bi-directional
Input ........................................................................ (TX) 1xHDMI; ( RX) 1xRJ45 + 2x3.5mm
Output ...................................................................... (TX) 1xRJ45 + 2x3.5mm; (RX) 1xHDMI
HDMI source control .................................................. Controllable via IR pass-through from RX to TX and
from TX to RX with IR extenders or via CEC integrated
HDMI connector ....................................................... Type A 19 pin female
RJ-45 connector ........................................................ WE/SS 8P8C
LED indicators ........................................................... Video lock yellow, Power, green
3.5mm connector ...................................................... (TX and RX) IR Receiver/ IR blaster
MECHANICAL SPECS
Housing .................................................................... Metal enclosure
Power supply ............................................................. (1)12V1A
Power consumption .................................................... 3.5 Watts TX, 2.5 Watts RX
Operation temperature ............................................... 32-104 degrees F
Storage temperature.................................................. -4 - 140 degrees F
Relative humidity ....................................................... 20-90% RH (no condensation)
PACKAGE CONTENTS
• EVEX2006 (TX & RX)
• (2) IR Blasters (TX)
• (2) IR Receivers (RX)
• (1) DC 12V in line power supply
• Product Manual
