3. Maintenance
Risk of electric shock. Before performing any maintenance or servicing, always
disconnect the unit from its power source.
Sharp edges may be present. When cleaning the unit, it is recommended to
wear safety glasses and gloves.
3.1 Quarterly Maintenance
WARNING
!
VD0244
1
2
1) Core 2) Core filters
Refer to picture beside to identify the inner parts of your
unit.
VD0005
1. Unplug the unit.
2. Remove the unit door by following these steps:
A. Remove both door lower machine screws no. 8-32 x 1” (1) and set aside.
B. Open (2) and lift out the door (3).
VO0191
AB
1
2
3
