29
2.1 Loosen the bolts on the side of the
handlebar using the Allen key #5.
2.2 Lift it up to the top of the internal stem,
then tighten one of the bolts to keep
it in position. Be careful to not detach
the handlebar completely as this may
damage the internal wiring.
2. 3 Place together one or two spacers to
raise the handlebar to your preferred height
(A). Then slide them down (B)(A). Then slide
them down (B).
Allen key #5
Allen key #5
2. Adjusting the handle bar height
B
A
