Vanward GD4819S - Page 8

8
Step5: Attach the Door Handles (C7) onto the Left Door (C9) and Right Door (C3) using
M4×8 bolt & Ø4 spring washer as shown.
M4*8
4 pcs
C9
C3
C7
D5
D5
Step6: Fit the doors to the cabinet by placing them into the door axes and then depressing
the spring pins to insert into the upper body support.
