Varian ProStar - Page 10

9 -Pin connectors
serial communication ribbon
Back connectors for 210/218
(To internal CIM)
INJECT
ADVANCE
PEAK
A-GND
ANALOG
RACK
EVT MARK
+13VDC
GND
CHASSIS
OUTPUTS INPUTS
1 2 3 4 5
7725i
ProStar 701
comm1
comm2
03-935462-91
CPU
P1 cable P2 cable
ProStar 410
AutoSampler
ProStar 210/218
Pumps
ProStar 363
Fluorescence Detector
GPIB Interface
connected to
comm1 or
comm2
Fan
PROCESSOR
RECORDER
READY/BUSY OUT
ERROR OUT
START IN
AUTO ZERO OUT
LAMP OFF
MARKER IN
Serial out
Power
0393592201
R007200141
Can send data to
800 MIB using the
cable PN 390793806
3
1
2
ANALOG
OUT GRD
INTGR 1
HI
INTGR 1
LOW
INTGR 1
GRD
CHASSIS
GRD
ANALOG
OUT
AUX
+5V
AUX
GND
STOP
D GRD
HOLD
D GRD
TRANSFER
D GRD
INJECT
D GRD
MARK
D GRD
Star WS Control of
ProStar 210/218 Pumps,
363 Fluorescence Detector, and
410 AutoSampler
