Varian ProStar - Galaxie CDS Control through 800 MIB of ProStar 230 Pump, 310 UV Detector and 410 AutoSampler

serial communication ribbon
INJECT
ADVANCE
PEAK
A-GND
ANALOG
RACK
EVT MARK
+13VDC
GND
CHASSIS
OUTPUTS INPUTS
1 2 3 4 5
ProStar 701
03-935462-91
P1 cable P2 cable
ProStar 410
AutoSampler
1v 10V
1mV 10mV
Data system
output 2AUFS
Chart recorder
Output
Peak sensing relay
Device Address
Relay 1
Relay 2
Relay 3
Relay 4
J9
J10
Syn Signal
Connected to GPIB
slot in the CPU using
cable PN 81-839700-00
ProStar 310 UV Detector
1v 10V (switch)
1mV 10mV (switch)
Data system
output 2AUFS
Chart recorder
Output
Peak sensing relay
Device Address
Relay 1
Relay 2
Relay 3
Relay 4
J9
J10
Syn Signal
Start In -
Start In +
Ready In -
Ready In +
Fault In -
Fault In +
Gnd
Gnd
J9
Start Out -
Start Out +
Ready Out -
Ready Out +
Fault Out -
Fault Out +
Ready In enable
+5V
J10
GPIB cable
PN 81-839700-00
-
Position sensing
switch of Rheodyne
manual injector is
connected to Start In
ProStar 230 Pump
Galaxie CDS Control through 800 MIB
of ProStar 230 Pump, 310 UV Detector
and 410 AutoSampler
800 MIB
Connect to
comm 1, 2, 3 or 4
03-907938-14
GPIB Cable Extender
81-839794-00
Network
