Varian ProStar - Page 7

9-Pin connectors
serial communication ribbon
Back connectors for 210/218
(To internal CIM)
3
1
2
ANALOG
OUT GRD
INTGR
1
HI
INTGR 1
LOW
INTGR 1
GRD
CHASSIS
GRD
ANALOG
OUT
AUX
+5V
AUX
GND
STOP
D GRD
HOLD
D GRD
TRANSFER
D GRD
INJECT
D GRD
MARK
D GRD
7725i
comm1
comm2
03-935462-91
CPU
P1 cable P2 cable
ProStar 410 AutoSampler
ProStar 330 PDA Detector
ProStar 210/218 Pumps
D-line
connectors
GPIB Interface
p/n 81-839700-00
START (+)
GROUND (-)
p/n 03-935716-01
To Inject & ground
of the 210/218 CIM
back connector
Star WS Control of
ProStar 210/218 Pumps,
330 PDA Detector, and 410 AutoSampler
7
