Varian ProStar - Page 6

9-Pin connectors
serial communication ribbon
Back connectors for 210/218
(To internal CIM)
3
1
2
ANALOG
OUT GRD
INTGR 1
HI
INTGR 1
LOW
INTGR 1
GRD
CHASSIS
GRD
ANALOG
OUT
AUX
+5V
AUX
GND
STOP
D GRD
HOLD
D GRD
TRANSFER
D GRD
INJECT
D GRD
MARK
D GRD
7725i
comm1
comm2
03-935462-91
CPU
P1 cable P2 cable
ProStar 410 AutoSampler
ProStar 325
ProStar 210/218
Pumps
GPIB Interface
INJECT
ADVANCE
PEAK
A-GND
ANALOG
RACK
EVT MARK
+13VDC
GND
CHASSIS
OUTPUTS INPUTS
1 2 3 4
5
ProStar 701
Ethernet
Cable
Analog Cable 110744200
Channel A or B
R007200141
Star WS Control of
ProStar 210/218 Pumps,
325 UV Detector, 701 Fraction Collector
and 410 AutoSampler
6
