Page 22
ECS 5M
The 12 primary functions are:
•
1 Main set point temperature
• 2 Fan 1 minimum speed
• 3 Fan 1 duty cycle timer
•
4 Fan 2 relative set point temperature
•
5 Fan 2 minimum speed
• 6 Fan 3 relative set point
• 7 Fan 4 / Drip cool relative set point
•
8 Fan 5 / Heater relative temperature set point
• 9 Ramping
• 10 Record low temperature display
•
11 Record high temperature display
•
12 Ambient temperature display
Any one of these functions is selected by rotating the Selector dial
to the corresponding number and associated graphical image
printed on the faceplate of the ECS. When primary functions 1
through 11 are selected, the LED status window displays a blinking
value. Function 12 displays ambient temperature.
The 11 secondary functions are:
• 1 Relative humidity setting
•
2 Fan 1 motor compatibility
•
3 Fan 1 differential temperature
• 4 Fan 2 differential temperature
•
5 Fan 2 motor compatibility
•
7 Drip Cool duty cycle timer
• 8 Fan 5 / Heater differential
• 9 Ramping minimum temperature limit
•
10 Low temperature alarm
• 11 High temperature alarm
• 12 Relative humidity display
Select any one of these secondary mode functions by:
• rotating the Selector dial to (12)
• rapidly rotating the Adjustor dial back and forth to enter secondary
mode.
•
rotating the Selector dial from function (12) to any other function.
When secondary functions 1 through 5, and 7 through 11 are
selected the status window displays a blinking value along with a
scrolling LED display. Selection of function 12 removes the ECS
from the secondary function mode.
