Varifan ECS 5M - Record Form

Page 50
ECS 5M
Dial Option Default setting User setting
1
Relative Humidity 65% 65%
2
Fan 1 Motor Compatibility 2 2
3
Fan 1 Differential 4°F 2°C
4 Fan 2 Differential 4°F 2°C
5 Fan 2 Motor Compatibility 2 2
7 Drip Cool Duty Cycle Timer 100% 100%
8 Temperature Differential 2°F 1°C
9 Minimum Ramping Limit 65°F 18°C
10 Low Temperature Limit -9°F -5°C
11 High Temperature Alarm 20°F 12°C
RECORD FORM
2nd Function
1
Main Set Point Temperature 77°F 25°C
2
Fan 1 Minimum Speed 24% 24%
3
Fan 1 Duty Cycle Timer ON ON
4
Fan 2 Relative Set Point 4°F 2°C
5 Fan 2 Minimum Speed 24% 24%
6 Fan 3 Relative Set Point 8°F 4°C
7 Fan 4 / Drip Cool Relative Set
Point
10°F 5°C
8 Heater / Fan 5 Relative Set Point -3°F -1.5°C
9 Ramping OFF OFF
