Varimixer V20 - Page 25

25
elecTrical componenTs
Fig. No. Description Part Number
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
Start Switch Assembly ...................................................................................... AR31-174.2
Stop Switch Assembly
.........................................................................................31-174.3
Timer Assembly
...............................................................................................W30-188.1Z
Timer ................................................................................................................W30-188.1
Timer Knob ........................................................................................................... 30-189
Front Panel ...................................................................................................RN20-650.30M9
Front Foil
........................................................................................................RN20-149.53
Motor Cable Grommet
........................................................................................ STA 3078
Cable inlet...........................................................................................................STA 3014
Nut .................................................................................................................... STA 3002
Bolt .....................................................................................................................STA 5432
Washer
...............................................................................................................STA 6008
Motor Mount Plate
................................................................................................20N-61
Nut ...................................................................................................................... STA 5851
Screw..................................................................................................................STA 5233
Contactor Bracket .............................................................................................. 20N-151.2
Auxiliary Switch ...................................................................................................20-88.47
Contactor 110V 16 A ............................................................................................100-88.4
Thermal Overload 11-16 ......................................................................................20-88.24
Motor 115V, 1 HP ............................................................................................... 20N-85.63
