Varimixer V20 - Table of Contents; I Nstallation and Fixing; Ommissioning; Ecommended Use of the Machine

4
Table of conTenTs
insTallaTion and fixing:
The ambient temperature around the machine must not exceed 113
o
F.
If the mixer is placed on a table, it must always be bolted into the table top. The bolts xing the mixer on the pallet can be used
for this, no nuts are needed as there are threads in the bottom plate of the mixer (see page 5).
Electrical connection:
For the benet of service staff, it should be clear to see when the mains plug to the mixer has been removed from the socket in
the wall.
Ensure that the voltage, phase and hertz printed on the identication plate of the mixer are the same as that at the place of
installation. The identication plate is located at the top of the right side of the mixer. Be sure the mixer is properly connected
to the incoming power supply and the ground or earth connection is made. The arrow on the front of the planetary head (see
drawing 2, page 1), indicates the direction of rotation of the planetary head. On three-phase motors the direction of rotation can
be changed by interchanging two phases of the connecting cable or the motor. Electrical connections must be made in accord-
ance with local regulations.
commissioning:
Bowl, tools and safety guard should be cleaned before use – see section on Cleaning, page 6.
recommended Use of The machine:
The machine is designed for the manufacture of products that do not trigger any reactions or release substances that may be
harmful to the user when in use.
The machine must not be used in an explosive atmosphere.
The mixer is designed for commercial use in kitchens, catering outlets and bakeries.
The machine may only be used as specied in this manual.
Unless the change is recommended by the manufacturer, modifying the machine is prohibited.
If the machine is tted with an attachment drive, only accessories produced or recommended by Varimixer should be attached.
Unpacking: ........................................................................................................................................................2
TransporT: ....................................................................................................................................................... 2
insTallaTion and fixing: ...................................................................................................................................4
commissioning: ................................................................................................................................................. 4
recommended Use of The machine: ................................................................................................................... 4
consTrUcTion of The mixer: ............................................................................................................................. 5
Technical daTa: ................................................................................................................................................ 5
The maximUm capaciTy of The mixer: .................................................................................................................5
dimension skeTch: ............................................................................................................................................ 5
safeTy: ............................................................................................................................................................. 6
correcT Use of Tools: .....................................................................................................................................6
aTTachmenT hUb: ..............................................................................................................................................6
recommended max. speeds ............................................................................................................................... 6
operaTing insTrUcTions ....................................................................................................................................7
overloading: ....................................................................................................................................................8
cleaning: ..........................................................................................................................................................8
lUbricaTion and grease Types: ........................................................................................................................8
service insTrUcTions ........................................................................................................................................9
machine colUmn ............................................................................................................................................14
lifTing sysTem ................................................................................................................................................ 16
pUlley sysTem ................................................................................................................................................18
planeTary head .............................................................................................................................................20
aTTachmenT hUb ............................................................................................................................................. 22
elecTrical componenTs .................................................................................................................................24
bowl screen ................................................................................................................................................. 26
Tools and aTTachmenTs ................................................................................................................................ 28
elecTrical diagram ....................................................................................................................................... 30
