11-03
EP E series
Illustrations may differ from the actual product
Allowing for printing errors and errors on proofs
5
Technical data
* I f five-core cable is used, remove the jumper on the neutral termi-
nal.
** Other pressure classes available.
21-22. Immersion heaters.
32. Supply/safety pipe R32 external thread.
33. Return pipe R32 external thread.
34. Drain valve R15.
35.
Opening cover for electrical connections.
36. Cable bushing.
37. Adjustable base bolts.
EP 26 E EP 42 E
Power
26.25 42 kW
Current
37.9 61 A
Power stage
3.75 6 kW
Current/stage
5.4 8.7 A
Connecting cable, max
16 25* mm
2
Both models
Voltage
400V3N~, 50Hz
Cable fitting
Ø 37 mm
Volume of water
17 litre
Test pressure
5.7 bar
Operating pressure
4** bar
Max temperature
110 °C
Operating temperature
20-95 °C
Pipe connection
R 32 ext. thread
Weight
50 kg
Protection class
IP 24
21
22
32
33
34
35
36
37
32
33
34
