VT121 All Weather User’s Guide 150-183
SPECIFICATIONS
ENGINEERING SPECIFICATIONS – VT121XB
Panel Size 12.1” (31cm)
Type Active Matrix Color Thin Film Transistor (TFT)
Native Panel Resolution XGA
Pixel Format 1024 (H) x 768 (V)
Pixel Pitch 0.240 (H) x 0.240 (V) mm
Pixel Arrangement RGB (Red dot, Green dot, Blue dot) vertical stripe
Dot Pitch 0.080 (H) x 0.240 (V) mm
Active Display Area
9.676” x 7.257”
245.76mm x 184.32mm
Viewing Angle (Left/Right)
70/70
o
(typ.)
Viewing Angle (Up/Down)
45/55
o
(typ.)
Color Gamut 40% (typ.)
Brightness 1000 Nits (typ.)
Contrast Ratio 600:1 (typ.)
Dimming Ratio 5000:1 (min.)
Response Time 25ms (typ.)
Back Lights 1 LED Rail rated 70,000 Hrs.
Video Connectors LEMO IP67
Colors Supported 16,777,216 (8-bit input)
Video Input Analog 0.7v p-p, TTL
Sync Separate H & V, Combined, SOG
Input Voltage 9 to 36VDC (12VDC typ.)
Power consumption 32 Watts (40 Watts with heater)
Temperature
Operating: -20 to 70ºC (optional -40 to 70ºC)
Humidity Operating/Storage: 0 to 100 %NC
Operating Altitude
Operating: Up to 10,000 ft
