VT121 All Weather User’s Guide 150-183
Read these instructions completely before attempting to operate your new LCD Color Display.
Page
Page
Section 1 Introduction
Section 4 Touchscreen
1.0 Overview 3 4.1 Touch Screen Introduction 14
1.1 VT121 General Features 3 4.2 Touch Screen Installation 14
1.2 Product Safety Precautions 3
Section 2 Display Setup Section 5 Troubleshooting
2.1 Inspection 4 5.1 General 15
2.2 Unpacking 4
2.3 Included Parts 4 Section 6 Maintenance
2.4 Installation Guidelines 4-5 6.1 Cleaning 16
2.5 Video Input Connections 6
Specifications 17-18
Section 3 Getting Started
3.1 Adjusting the display 7 Mechanical Drawings 19-20
3.2 OSD Adjustments 8-13
