Vasco E-Volve E-V-RF User Manual

5 sec.
5 BINDING THE CONTROLLER WITH THE
RF REMOTE CONTROL
The RF remote control and the RF receiver are not paired at the factory.
Attention:
A maximum of 5 RF receivers can be connected to 1 RF remote control
Proceed as follows and do this for each RF receiver:
RF pairing:
1. Put the RF receiver in pairing mode by pressing the Memo button for 5 sec.
RF LED will start to blink in RED.
2. Put the RF remote control in frost protection mode by pressing the button 3x
and press for 5 sec.
5 sec.
3. To get an accurate estimations of the power consumption, the radiator's power
must be assigned to the Controller, by default it is set to 500W. Use the and
keys to set the power (see rating plate radiator).
4. When the RF remote control and the RF receiver
are linked, the symbol appears and is
constantly displayed
RF
02 BINDING THE CONTROLLER WITH THE RF REMOTE CONTROL

Vasco E-Volve E-V-RF Specifications

General

Brand	Vasco
Model	E-Volve E-V-RF
Category	Controller
Language	English
