4. Installing the X-ray Unit: Base Stand Type
40 Green X / X18 (Model: PHT-75CHS) Installation Manual
2. Put two wrench bolts into the holes on the bottom of the column unit.
Required Tool Allen Wrench 6 mm / 0.24”
Parts and
Accessory
Wrench Bolt
M8 x 35 - 2 pcs
(Part No. 24)
Leave the bolts 30mm outside of the hole.
