9
assembly / usage
5. After wrapping the tube around the hose, affix
Solution Tube (A) to Hose (B) using Clips provided (C) to
hold it in place (Fig.7/5).
6. Push the second extension tube into the wash head to
be used and push the end of the solution tube onto the
connection port on the Wash Head / Upholstery Tool
(Fig.7/6).
8. Usage
1. Plug in machine to power supply.
2. Press the red button to turn on the power.
3. Press the green button to activate the pump.
Washing Carpets
1. On the Fibreflow wash head ensure that the rocker
switch (A) is towards the back of the head to allow water
to flow through the head (Fig.8/1).
2. In order to help suck up excess water, the rocker switch
(A) can be pushed to the front position on the Fibreflow
was head. This will prevent water flow, allowing excess
water to be removed (Fig.8/2).
Washing Upholstery
1. Detach wash head from the solution tube and
extension tubes.
2. Pull the extension tube out of the handle of the hose.
3. Attach the upholstery wash tool directly onto the
handle of the hose (Fig.8/3) and wrap the excess solution
tube around as necessary.
Fig.7/4
Fig.7/5
Fig.7/6
B
A
C
A
B
Fig.8/1
Fig.8/2
A
A
Vax 6121(C) User Guide v1.qxd 19/11/07 15:10 Page 9
