5
vacuuming
Replace the motor top, ensuring that the dust bag is not
trapped. Ensure the motor top is secured to the base with
the two clips (Fig.3/8).
Insert the flexible hose into the inlet on the main body of
the vacuum cleaner. Push in and twist clockwise a quarter
turn until tight (Fig.3/9).
Push the extension tubes onto the end of the handle
(Fig.3/10).
Fit the combination floor tool by pushing on to the
extension tube (Fig 3/11).
On/Off Button
Fully unwind the power cord and plug the cord into the
electrical outlet. Turn the vacuum cleaner on by
depressing the button located on the top of the carry
handle (Fig.3/12). The vacuum cleaner can be turned off
by pressing the on/off button again.
Fig.3/7
Fig.3/8
Fig.3/9
Fig.3/10
Fig.3/11
Fig.3/12
Vax 6121(C) User Guide v1.qxd 19/11/07 15:10 Page 5
